Home / 60mm 15W 3000RPM 100-220V BLDC Gear Motor

60mm 15W 3000RPM 100-220V BLDC Gear Motor

$30.4-$32.4

This 15W 60MM BLDC Gear Motor features an efficient brushless DC motor design, providing superior performance and reliability without the need for regular maintenance. This motor makes an ideal choice for high-powered applications such as robots, drones, and other automated solutions.

Model TypeDC Motor

Voltage(V)100-220

Output(W)15

Size(mm)60

Speed(RPM)3000

SPECIFICATIONS

Model Voltage (V) Frequency (HZ) Rated Power (W) Rated Current (A) Rated Speed (RPM) Rated Torque (N.m) Grade Protection IP
Z2BLD15-220GN 220-230 50/60 15 0.35 3000 0.047 65
100-120 50/60 10 0.65 3000 0.047 65

Product Display

This motor has the optional accessories: gearbox, controller, encoder, brake.

For DC brushless motor, we can make from 10W to 500W with all voltage and speed ratio.

Motor voltage,power and speed will be customized according to your requests under the allowed circumstance of adoptable dimension

If you have interest or demand, you can send inquiry for details

Product Feature

Brushless DC Design

This 15W 60MM BLDC Gear Motor features an efficient brushless DC motor design. It offers superior performance and reliability without the need for regular maintenance, making it a versatile choice for multiple applications.

Versatile

The motor is suitable for high-powered applications, including robotic devices, drones, and other automated solutions. Its reliable power output and durable build ensure it can handle demanding tasks effortlessly.

Customizable

The motor's voltage, power and speed can be customized according to your requirements, ensuring a perfect fit for your specific application.

Optional Accessories

The motor comes with optional accessories, including a gearbox, controller, encoder, brake. These additional features increase the motor's functionality and adaptability to various scenarios.

Wide Voltage Range

With a voltage range of 100-220V, this motor assures adaptability across a wide array of operating conditions, making it a reliable and versatile option for multiple applications.

Product Applications

Robotic Devices

The motor's high power output and reliable operation make it an excellent choice for various robotic applications where precise movement and performance are paramount.

Drone Technology

The motor's reliable operation, coupled with its substantial power output, make it suitable for use in drone technology, providing consistent propulsion and stability.

Automated Solutions

The motor is also suitable for automated solutions where reliability and efficiency are critical. Its durable build ensures it operates effectively even under strenuous conditions.

Videos

DIMENSIONS

Technical Documents Downloads

File NameSizeDownload
ZY60-F60-15W-2GN-GEAR-MOTOR.STEP11.0MBDownload
DC-Motor-Catalog.pdf55.7MBDownload
