Home / 90mm 40W 3000rpm 110/220V BLDC Gear Motor

90mm 40W 3000rpm 110/220V BLDC Gear Motor

$

This 40W 80MM BLDC Gear Motor is a reliable and powerful motor with a 40W innovative brushless DC design, ensuring performance and durability. It features 80MM gear diameter for increased torque and precision control, making it an ideal choice for a range of motion-control applications.

Model TypeDC Motor

Voltage(V)110/220

Output(W)40

Size(mm)90

Speed(RPM)3000

Product Display

This motor has the optional accessories: gearbox, controller, encoder, brake.

For DC brushless motor, we can make from 10W to 500W with all voltage and speed ratio.

Motor voltage,power and speed will be customized according to your requests under the allowed circumstance of adoptable dimension

If you have interest or demand, you can send inquiry for details

Product Feature

Brushless DC Technology

Integrating advanced brushless DC technology, this 40W gear motor ensures high efficiency and reliability, delivering superior performance with less noise and longer lifespan.

Customizable Configuration

Offering a wide range of customizable options, including gearbox, controller, encoder, and brake, to precisely meet the specific requirements of various applications.

High Torque Precision Control

With its 90mm flange design, the motor provides increased torque for accurate speed and position control, suitable for precision movement in complex systems.

Energy-Saving Operation

Designed for cost-effective operation with optimized power consumption, making it an eco-friendly addition to any setup without compromising performance.

Robust Protection

Secured with Grade Protection IP65, the motor is protected against dust ingress and low-pressure jets of water, suitable for rigorous industrial environments.

Product Applications

Industrial Automation

Reliable control for conveyor belts, assembly lines, and automated manufacturing systems.

Precision Instrumentation

Essential for applications requiring exact positioning in medical devices, precision sampling instruments, and laboratory equipment.

Robotics and CNC Machines

Provides the necessary performance and control for robotics, CNC machining, and other complex machinery.

Energy-Efficient Home Appliances

Suitable for powering modern, energy-saving home appliances that demand quiet operation and durability.

Custom Mobility Solutions

Ideal for custom mobility projects such as electric vehicles, automated guided vehicles (AGVs), and personal mobility devices.

Videos

SPECIFICATIONS

Model Voltage(V) Frequency(HZ) Rated Power(W) Rated Current(A) Rated Speed (RPM) Rated Torque (N.m) Grade Protection IP
Z5BLD40-220GN 220-230 50/60 40 0.40 3000 0.127 65
100-120 50/60 40 0.80 3000 0.127 65

DIMENSIONS

Technical Documents Downloads

File NameSizeDownload
Z5BLDL-Model.pdf577KBDownload
DC-Motor-Catalog.pdf55.7MBDownload
