40W 12-90V 80mm Brushless PMDC Gear Motor

Home > 40W 12-90V 80mm Brushless PMDC Gear Motor

40W 12-90V 80mm Brushless PMDC Gear Motor

$34.82 - $43.54

This CNC router is designed to provide excellent power and torque performance, featuring a 500-710W spindle and an 8080 desktop metal router for woodworking and engraving. It is equipped to handle intricate cutting with its high-torque motor for precision results.

Motor Typegear motor

Output Power (W)40

Voltage (V)12-90

Rated Speed (r/min)2800-3000

40W 80mm DC Motor
Model Voltage Power No-load Parameters Load Parameters Brush Life Motor Weight
Speed Current Speed Torque Current
V W r/min A r/min mN.m A H kg
L4D40-12 12 40 3100 2.0Max 2800 136 5.2 2000 1.8
L4D40-24 24 40 3100 0.8Max 3000 127 2.1 2000 1.8
L4D40-90 90 40 3200 0.3Max 3000 127 0.7 2000 1.8

Product Display   / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / /

40W 12-90V 80mm Brushless PMDC Gear Motor

Feature   / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / /

Brushless PMDC Gear Motor

This motor, designed for optimal performance, offers an impressive power output of 40W and a wide operating voltage of 12-90V. With a brushless PMDC design, get ready for a higher degree of efficiency and long-life performance.

Impressive Speed

With a rated speed of 2800-3000RPM, it enables fast and efficient operations, accommodating a range of automation and motor control needs.

Scope of Models

Three model options are available suited for different voltage requirements - L4D40-12 (12V), L4D40-24 (24V), and L4D40-90 (90V). Select the one that best fits your demand and get the advantage of varied speed, torque, and current parameters for smooth operations.

Superior Performance

This CNC router-equipped powerful gear motor encompasses a spindle power of 500-710W for immaculate woodworking and engraving tasks, offering precision in even intricate cutting actions.

Sufficient Brush Life

Each model offers a decent brush life of 2000 hours, making the motor a cost-effective and rustic choice for long-term use.

Motor Weight and Size

The motor has a compact size of 80mm with a weight of 1.8kg, making it easy to install and manage in various systems.

Applications   / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / /

High-Torque Operations

Featuring a high-torque motor, it is suitable for precise and intricate cutting tasks.

Speed Critical Operations

With an impressive rated speed between 2800-3000 rpm, it powers applications that require high-speed operations.

Voltage Sensitive Tasks

Its wide operating voltage range allows it to be employed in tasks that operate in varied voltage environments.

40W 12-90V 80mm Brushless PMDC Gear Motor
