SPECIFICATIONS
Electrical Specifications
| Manufacturer Part Number | 86IBL400-4830 |
| Inductance(mH) | 0.51 |
| No. of Phase | 3 |
| Phase Resistance(ohm) | 0.21 |
| Product Type | Integrated BLDC Motor |
| Rated Current(A) | 8.33 |
| Input Voltage(V) | 48 |
| Holding Torque(Ncm) | 127 |
| Holding Torque(oz.in) | 179.85 |
| Rated Power(W) | 400 |
| Rated Speed(rpm) | 3000 |
| Insulation Class | Class B |
| Resistance/phase | 0.21±10%Ohms |
| Inductance/phase | 0.51±20%mH |
| Sensor | HALL |
Physical Specifications
| Inventory Method | Shared Inventory |
| Frame Size(mm) | Nema 34 (86 x 86) |
| Body Length(mm) | 168 |
| Shaft Diameter(mm) | 14 |
| Shaft Length(mm) | 32 |
| Weight | 3.12kg |
Product Feature
High Efficiency
This integrated brushless DC motor offers high efficiency, ensuring optimal performance and energy savings.
Compact Design
Features a compact design with NEMA 34 mounting, ideal for space-constrained applications.
Powerful Performance
Provides a power output of 400W, delivering robust and reliable performance for various applications.
Precise Speed Control
Operates at 3000RPM, offering precise speed control for demanding tasks.
High Torque
Delivers a high torque of 1.27Nm, making it suitable for applications requiring strong rotational force.
Integrated Design
Combines the motor and controller in a single unit, simplifying installation and reducing wiring complexity.
Low Noise Operation
Designed to operate with low noise, ensuring a quieter working environment.
Product Applications
Industrial Automation
Ideal for industrial automation, providing precise and reliable motion control for production lines and machinery.
Robotics
Suitable for robotics applications, offering dependable performance for various robotic components and systems.
CNC Machines
Perfect for CNC machines, ensuring accurate and powerful motion control for cutting, milling, and engraving tasks.
Medical Equipment
Used in medical equipment, providing reliable and precise performance for diagnostic and therapeutic devices.
Packaging Machinery
Applicable in packaging machinery, ensuring efficient and accurate operation for packaging processes.
Automated Guided Vehicles (AGVs)
Suitable for AGVs, providing reliable motion control for automated material handling systems.
Laboratory Automation
Ideal for laboratory automation, offering precise and dependable performance for various automated lab equipment.
