300W 90MM BLDC Gear Motor

Home > 300W 90MM BLDC Gear Motor

300W 90MM BLDC Gear Motor

This 300W 90MM BLDC Gear Motor offers reliable efficiency and power for a variety of uses. Its 90MM brushless design and BLDC motor provide durability, while its 300W output offers a brisker performance than others in its class. Ideal for industrial applications.

Power (W)300

Voltage (V)36~72

Flange (mm)90


Model Voltage
(V)
Rated Power
(W)
No-load Parameters Load Parameters Motor Life
(H)
Motor Weight
(kg)
Speed
(RPM)
Current
(A)
Speed (RPM) Torque
(N.m)
Current
(A)
Z5BLD300-36 36 300 3500 Max 1.0 3000 0.96 10.5 >5000 2.0
Z5BLD300-48 48 300 3400 Max 0.75 3000 0.96 8.0 >5000 2.0
Z5BLD300-72 72 300 3300 Max 0.50 3000 0.96 5.5 >5000 2.0

Overview

This motor has the optional accessories: gearbox, controller, encoder, brake.

For DC brushless motor, we can make from 10W to 500W with all voltage and speed ratio.

Motor voltage, power and speed will be customized according to your requests under the allowed circumstance of adoptable dimension

If you have interest or demand, you can send inquiry for details

Gearbox Ratio, Speed and Torque:

300W 90MM BLDC Gear Motor

Dimension Drawing

300W 90MM BLDC Gear Motor
