SPECIFICATIONS
Electrical Specification
| Property | Value |
|---|---|
| Manufacturer Part Number | 57BLR43-36-01 |
| Phase | 3 |
| Poles | 4 |
| Rated Voltage | 36V |
| Rated Speed | 4400±10%RPM |
| Rated Torque | 0.055Nm (7.79oz.in) |
| Rated Current | 1±10%A |
| Rated Power | 25W |
| Insulation Class | Class B |
| Insulation Resistance | 100MΩ Min @500VDC |
| Dielectric Strength Test | 500VAC for 1 Minute |
Physical Specification
| Property | Value |
|---|---|
| Frame Size | Φ57mm |
| Body Length | 43mm |
| Shaft Diameter | Φ8mm |
| Shaft Length | 25mm |
| Shaft Type | D-cut |
| D-cut Length | 20mm |
| Number of Leads | 8 |
| Lead Length | 300mm |
| Bearing Type | NMB Ball Bearing, C3 |
| Weight | 0.4kg |
