SPECIFICATIONS
Electrical Specification
| Manufacturer Part Number | 57BLR70-24-01 |
| Phase | 3 |
| Poles | 4 |
| Product Type | BLDC Motor |
| Rated Current(A) | 9 |
| Rated Power(W) | 134 |
| Rated Speed(rpm) | 3500 |
| Rated Torque(Nm) | 0.37 |
| Rated Voltage(V) | 24 |
| Insulation Class | Class B |
| Insulation Resistance | 100MΩ Min @500VDC |
| Dielectric Strength Test | 500VAC for 1 Minute |
Physical Specification
| Inventory Method | Dedicated Inventory |
| IP Rating | 20 |
| With Gearbox | No |
| Frame Size(mm) | Nema 23 (57 x 57) |
| Body Length(mm) | 69.1 |
| Output Shaft Type | O |
| Shaft Diameter(mm) | 8 |
| Shaft Length(mm) | 25 |
| Shaft Type | D-cut |
| D-cut Length | 20mm |
| Number of Leads | 8 |
| Lead Length | 300mm |
| Bearing Type | NMB Ball Bearing, C3 |
| Weight | 0.75kg |
